Product Details:
|
Nominal Capacity: | Nominal Voltage: | ||
---|---|---|---|
Internal Impedence: | Operating Votage: | ||
Dimension: | Battery Weight: | 12kg |
1.360v portable electric car charger 3.3kw sae j1772 best ev charger
The onboard charger is an essential feature in any new energy vehicle. The primary functions of the On-Board Charger (OBC) include the following: Grid charge is transferred to the charger via its grounded AC charging pile as well as its AC charging port, which is used to slowly charge the battery that powers the onboard. The general rule is that new energy vehicles come with two kinds of "experiences" that include experiencing the driving and charge experience. Charge experience is an exceptional experience for the new generation of vehicles. The continuous improvement of the experience for charging is vital to the development and research of high-end onboard chargers.
Whatever the design, housing or style, energy output, plug type, or length of cable We can design it in accordance with your requirements. With our product portfolio as well as services we offer easy, efficient, and well-suited charging options that fulfill your needs individually for commercial and domestic applications.
Because of our unique blend of knowledge and expertise in the automotive industry and charger knowledge. With a long-standing track record in the auto industry Our quality-oriented policy and creative thinking. We offer a variety of high-performance charging solutions to a variety of automobile manufacturers. Intelligent charging stations as well as digital solutions allow charging electric vehicles to be simple and effective.
2. 360v 3.3kw Charger Parameter Specification:
Item | Parameter | |
Spec | Type | 3.3KW Air-cooled OBC |
Output Voltage | 360V | |
Charging mode | Response mode | |
Input | Input voltage | 90V-265V |
Frequency | 50Hz | |
Inrush current | ≤16A | |
Input power factor | ≥0.99 (@220Vin,Pomax) | |
Output | Output power | 3.3KW |
Range of output voltage | 0~440V | |
Range of output current | 0~9A | |
Voltage regulation accuracy | ≤1% | |
Voltage ripple coefficient | ≤1% | |
Current regulation accuracy | ≤5% | |
Output response time | ≤5S | |
Typical efficiency | ≥93% | |
Output voltage of low voltage module | 12V±1V | |
Output power of low voltage module | 2W |
3. Detailed Images:
4.Other popular products recommended.
When we first started in the beginning, we did more than electricize the vehicle We also sparked the imagination. Since then, we've created our electric vehicle infrastructure. We also offer a top-selling 6.6KW charger.
