Product Details:
|
| Input Voltage: | AC 380V | Rated Power: | |
|---|---|---|---|
| Output Voltage: | 80V | Output Current: | 10A-200A |
| Dimension: | 450X350X280(mm3) | Weight: |
We provide the latest production of lithium forklift chargers, electric car chargers, electric bus chargers, vehicle chargers, electric forklift chargers, golf cart chargers, high power DC power supply using high frequency switching power supply technology, digestion and absorption of advanced control technology (CAN-BUS) at home and abroad, designed to 48V ~ 600V. Module full-bridge inverter power supply technology. The transformer with nanocrystalline soft magnetic material is small in size, light in weight for lithium forklift charger, tightly coupled, evenly distributed current, and easy to assemble. It effectively solves the interference of the power grid to the power supply and the influence of the harmonics of the power supply to the power grid, improves the reliability of the power supply and increases the average failure-free time of the power supply, which is a practical, functional, anti-interference capability, high output power and high reliability product . It has the characteristics of light weight, small volume, shockproof, salt spray proof, high efficiency, low interference, safe and reliable.
It has been widely used in: electric forklift, sightseeing touring car, golf cart, electric handling car, mining battery locomotive, electric tractor, electric cruise ship, military equipment and other fields.
Model | 80V100A | 80V150A | 80V200A |
Dimension(mm) Size(mm) | 480*480*775 / 410*500*505 | 450*350*550 | 480*480*775 / 420*420*740 |
Net Weight | 74KG / 40KG | 45KG | 90KG / 64KG |
Input parametersInput | AC 380V ±15%, 50Hz/60Hz | ||
Input Wire | 3*4+1*2.5mm2 (Three phases+Ground ) 3.5m | 3*6+1 *4mm2 (Three phases+Ground) 3.5m | |
Output Voltage | Suitable for 80V battery packs (customisable) | ||
Output Current | 10A-100A | 15A-150A | 20A-200A |
Efficiency | >92% | ||
Dielectric Strength | (Input - Output): 2500VAC 5mA,1 Min (Input - Housing)： 2500VAC 5mA,1 Min (Output - Housing)： 1500VAC 5mA,1Min | ||
Insulation Resistance | (Input-Output)： DC1000V>200MQ (Input - Housing)： DC1000V>50MQ (Output - Housing): DC1000V>50MQ | ||
Conversion Frequency
| 18kHz ± 2kHz (three-phase full-bridge IGBT module conversion circuit) | ||
Ingress Protection | IP 20 | ||
Cooling system | Forced Air-cooling | ||
Operating temperature | -10°C~45°C | ||
Storage or portage temperature | -40°C~60°C | ||
Humidity | 10%~90X：(No ice) | ||
Noise | w70dB | ||
Operational Environment | (Indoor) | ||
Altitude | below2000m | ||
Output Connector&Wire (Optional) | (GB Connector),about 3m / (REMA Connector),about3m | ||
